plastic ampoule filling and sealing Packing Machine
This machine is use for cosmetics, food, chemical products packaging, olive oil, syrup, seasoning sauce, ketchup, honey, oral liquid oil , eye care cream, fertilizer pesticides etc.
Automatic plastic ampoule forming , liquid filling, sealing, cutting .
Ampoule filling machine could have easy tear line making and date embossing.
Features:
PLC control , touching screen English Operation.
PID temperature Control.
Filling volume 0.5-200ml according to requirements.
Power supply:according to each country customer requirements.
Each machine has CE certificate
Model
DGS-240
Max Forming depth
12mm(OEM Design)
Cutting Frequency
1-25times/min
Packing Film
PVC/PE.PET/PE(0.2-0.4)*240mm
Filling volume
200ml
Power
7KW
Power Supply
380V50Hz(OEM)
Machine Weigh
1000kgs
Machine Dimension(L*W*H)
3200*950*1800mm
Application:
This machine is suitable for liquid, sticky, paste,cream product packaging for pharmaceutical ,food , cosmetic and daily use product etc. Such as medical oral drinking,healthy products,pesticide, perfume, oil,e-liquid, jam ,chocolate etc.
Main Features:
1.Main Line control,touching screen operation,frequency stepless for packing speed control.
2.Automatic Ampoule forming ,liquid dosing, filling, date or batch No. Embossing,sealing, cutting .
3.Accurate filling , no drop , no leaking, no bubbles.
4.All direct contact with product parts is made of stainless steel which meet GMP standard.
5.Photocell checking sensor to control logo or pattern on the product.
Automatic plastic ampoule liquid forming filling sealing machine it is the ideal packing machine for plastic ampoule, plastic vial , OEM shape product packing for liquid , cream , gel , sticky and non sticky products .
Working unit: automatic plastic ampoule forming , liquid dosing and filling , sealing with embossing for date or batch No. Cutting automatically .
Cosmetic essential oil , liquid ,food sauce , drinking products , olive oil , honey , ketchup,etc. Automatic forming filling sealing machine, according to requirements to design the product shape and size . different model machine fit for different capacity requirements .
All machines CE standard, ISO certificates with RoHS certified machines parts.
Certificate to fit for different country tax deduce and machine quality approvement .
