energy drinks plastic ampoule packaging machine/filling machine

Inquire Now Next Product

Specifications

Automatic Energy Liquid Drinks Packing Machine

This machine is suitable for packaging perfume, cosmetics, food, olive oil, syrup, seasoning sauce, tomato sauce, honey, oral liquid oil, eye cream, fertilizers, etc. Fully automatic plastic ampoule molding, filling, sealing, and cutting. Ampoule filling machines can have easy tear line production and date embossing. Features: PLC control, touch screen English operation. PID temperature control. The filling volume is required to be 0.5-200ml. Power supply: According to the requirements of customers in each country. Each machine has a CE certificate.

Model	DGS-188N2
Max Forming depth	12mm
Cutting Frequency	1-25times/min
Packing Film	PVC/PE.PET/PE(0.2-0.4)*120mm
Filling volume	0.5-60ml
Power	4.3KW
Power Supply	380V

Application:

This machine is suitable for liquid, sticky, paste,cream product packaging for pharmaceutical ,food , cosmetic and daily use product etc. Such as medical oral drinking,healthy products,pesticide, perfume, oil,e-liquid, jam ,chocolate etc.

Main Features:

1.PLC control,touching screen operation,frequency stepless for packing speed control.

2.Automatic Ampoule forming ,liquid dosing, filling, date or batch No. Embossing,sealing, cutting .

3.Accurate filling , no drop , no leaking, no bubbles.

4.All direct contact with product parts is made of stainless steel which meet GMP standard.

Model	DGS-188(N2)	DGS-188(N5)
Max Forming Depth	12mm	12mm
Cutting Frequency	1-25times/min	1-25times/min
Packing Film	PVC/PE.PET/PE(0.2-0.4)*120mm	PVC/PE.PET/PE(0.2-0.4)*120mm
Filling Volume	0.5-60ml	0.5-60ml
Power	4.3KW	4.5KW
Power Supply	380V50Hz
Machine Weight	550kgs	750kgs
Machine Size	17507501400mm	23008501500mm
