Automatic Sachet Packing Machine

Bottle Shape Sachet Packing Machine

Bottle Shape Sachet Packing Machine

Bottle Shape Sachet Packing Machine

This shaped bag sachet packing machine , could be used to pack liquid, cream , sticky product such as cosmetic, syrup , honey, drinks ,chemical products and so on .

*The working unit is from bag forming , dosing , filling , sealing to cutting with eye marking foundation and date or batch No. Letter coding (or ink printing).

PLC and touching screen is from Omron to ensure the machine control stable .



Schneider servo motor to control the sachet pushing ,bag forming accuracy could be assured .



Panasonic eye marking checking sensor to guide the forming and sealing in the correction position.



Temperature control and reply to be used the same brand Omron as PLC to ensure machine working synchronous.

All connect with product parts is made of stainless steel 304,(could be choosed for 316 depend on customer requirements , but ss 316 cost will be higher than ss304).

*The liquid packaging , the cylinder is from Taiwan AirTack, it’s the best choice in domestic for



liquid packaging .



* The machine is fit for GMP and CE standard.





II.Standard specification





Article

Liquid/cream/paste packaging





Model

SEM-IR60





Range of measure

1-50ml





Measuring Method

Pneumatic pump





Size of bag

L50-180mm   W20-150mm





Capacity

10-60 bags/min





Case of machine

Stainless steel #304





Power

2.5KW





Power supply

380V or 220V 50Hz/60Hz





Weight (Kg)

480kgs





Dimensions(mm)

850*1150*2150mm





Material of

Paper/polyethylenecellophane/polyethyleneplated


bag/Film

aluminum/polyethyleneBOPP/polyethylenenylon/polyethylene





Function

Automatically measuring volume, making bags, filling, sealing,


cutting,   cutting easy tearing notch, etc.
