Automatic Sachet Packing Machine

1-5 Grams 4/6/8/10 lanes multilanes powder granule sachet packaging machine with vacuum uploading pump

Multi lanes Sachet packing machine is used for packaging powder, granule, liquid, cream, honey, ketchup, jelly, jam, chocolate sauce, food, cosmetics, etc. And the sachet shape and size could be customized according to customer requirements. For example, three side sealing, four side sealing and back stick. Automatic sachet bag forming ,product dosing and filling ,sealing, cutting. Machine could install printer for date/batch No. printing and photocell sensor for pre-printed film packing, this is for choice ,according top customer requirements. OEM design the sachet type and size 1. Touch screen display, operation is sample. 2. PLC computer control system, more stable operation, without stopping to adjust any parameters. 3. Can stock ten, change variety. 4. Servo motor film pulling, positioning is more accurate. 5. Independent temperature control systems, precision up to ± 1 ℃ degrees. 6. Horizontal, vertical temperature control, can be suitable for various composite film, PE film packing material. 7. Mechanical material is 304 stainless steel, in line with food hygiene requirements. 8. Bag, sealing, packaging, print date in one. 9. Quiet working environment, noise.


Lanes quantity

4~6 lanes

4~10 lanes

4~12 lanes

Filling Material

Powder

Powder

Powder

Capacity

Max:40pc/min/lane

Max:40pc/min/lane

Max:40pc/min/lane

Sachet size

L:45-120mm W:35-60mm

L:45-120mm W:35-90mm

L:45-120mm W:35-120mm

Film width& thickness

Max:480mm;0.05-0.1mm

Max 720mm,0.05-0.1mm

Max 960mm,0.05-0.1mm

Sealing type

4 sides sealing

4 sides sealing

4 sides sealing

Power

2.8KW

2.8KW

2.8KW

Air consumption

 0.8 Mpa 0.8m³/min

 0.8 Mpa 0.8m³/min

 0.8 Mpa 0.8m³/min

Dimension

950*1470*1750mm

1153*1654*1750mm

1415*1686*2130mm

Weight

300 kgs

400 kgs

500 kgs
